SFC-1303 3kVA / SFC-375 75kVA Programmable AC Power Supply Sophpower
Programmable AC Power Supply
The SFC Series Programmable AC Power Source is integrated with the IGBT/SPWM technology. has the advantages of fast response speed, high output precision and superior waveform quality to achieve all kinds of industrial requirements.
The SFC Series Ac Power Source offers output power rating from 1kVA to 2000kVA, which has Three-phase Synchronous and independent modes and Parallel single phase mode (Opt.).
Features
- Output power from 1kVA-2000kVA.
- 7 touch panel and rotary knob operation.
- Three phase independent mode, three phase synchronous mode and parallel single phase mode (Opt.).
- Automatic high and low range voltage 0-150V/150.1-300V automatic switch, or 1-300V high range locked.
- Strong shock resistance, able to start the loads of 1/3 rated power of the AC power supply directly
- Output voltage and frequency adjustable at output state.
- Three phase Independent adjustable.
- Phase Angel adjustable for each phase.
- Standard RS232 interface, optional RS485, GPIB and Ethernet interface.
- With power-off memory function, remember the last output parameters automatically.
- IP/OP Isolation transformer design.
